Battery for NISSAN PATROL GR V (Generation 5) Wagon (Y61)
Compatible Car Batteries for NISSAN PATROL GR V (5) Wagon (Y61)
Model years: since 06.1997. Car body type: Closed Off-Road Vehicle
Battery Size Requirements
| Car Model Description | Model Years | Max Size | AVG Size | Min Size |
|---|---|---|---|---|
| NISSAN PATROL GR V (5) Wagon (Y61) 4.5 i | since 06.1997 |
20.2” x 8.9” x 8.78” 513 x 226 x 223 mm |
20.2” x 8.78” x 8.78” 513 x 223 x 223 mm |
20.16” x 8.78” x 8.66” 512 x 223 x 220 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TD | 06.1997 - 05.2000 |
20.2” x 8.9” x 8.78” 513 x 226 x 223 mm |
20.2” x 8.78” x 8.78” 513 x 223 x 223 mm |
20.16” x 8.78” x 8.66” 302 x 172 x 200 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.2 TD | since 06.1997 |
20.2” x 8.9” x 8.78” 513 x 226 x 223 mm |
20.2” x 8.78” x 8.78” 513 x 223 x 223 mm |
20.16” x 8.78” x 8.66” 512 x 223 x 220 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 |
20.2” x 8.9” x 8.78” 349 x 175 x 235 mm |
20.2” x 8.78” x 8.78” 306 x 173 x 222 mm |
20.16” x 8.78” x 8.66” 315 x 175 x 205 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 |
20.2” x 8.9” x 8.78” 513 x 226 x 223 mm |
20.2” x 8.78” x 8.78” 304 x 174 x 225 mm |
20.16” x 8.78” x 8.66” 315 x 175 x 205 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.8 | since 03.2000 |
20.2” x 8.9” x 8.78” 513 x 226 x 223 mm |
20.2” x 8.78” x 8.78” 306 x 173 x 225 mm |
20.16” x 8.78” x 8.66” 315 x 175 x 205 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TDiC (Y61) | 10.1997 - 02.2000 |
20.2” x 8.9” x 8.78” 303 x 175 x 227 mm |
20.2” x 8.78” x 8.78” 306 x 173 x 222 mm |
20.16” x 8.78” x 8.66” 302 x 172 x 200 mm |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.7 TD | 05.1998 - 06.2001 |
20.2” x 8.9” x 8.78” 306 x 173 x 225 mm |
20.2” x 8.78” x 8.78” 306 x 173 x 222 mm |
20.16” x 8.78” x 8.66” 315 x 175 x 205 mm |
Battery CCA Requirements
| Car Model Description | Model Years | Max CCA | AVG CCA | Min CCA |
|---|---|---|---|---|
| NISSAN PATROL GR V (5) Wagon (Y61) 4.5 i | since 06.1997 | 1150 | 1000 | 815 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TD | 06.1997 - 05.2000 | 1150 | 900 | 630 |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.2 TD | since 06.1997 | 1150 | 1000 | 815 |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 | 850 | 750 | 630 |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 | 1150 | 830 | 630 |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.8 | since 03.2000 | 1150 | 830 | 630 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TDiC (Y61) | 10.1997 - 02.2000 | 850 | 740 | 630 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.7 TD | 05.1998 - 06.2001 | 850 | 800 | 680 |
Battery Capacity (AH) Requirements
| Car Model Description | Model Years | Max AH | AVG AH | Min AH |
|---|---|---|---|---|
| NISSAN PATROL GR V (5) Wagon (Y61) 4.5 i | since 06.1997 | 200 | 180 | 155 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TD | 06.1997 - 05.2000 | 200 | 155 | 90 |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.2 TD | since 06.1997 | 200 | 180 | 155 |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 | 115 | 95 | 90 |
| NISSAN PATROL GR V (5) Wagon (Y61) 3.0 DTi | since 05.2000 | 185 | 95 | 90 |
| NISSAN PATROL GR V (5) Wagon (Y61) 4.8 | since 03.2000 | 185 | 95 | 90 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.8 TDiC (Y61) | 10.1997 - 02.2000 | 105 | 95 | 90 |
| NISSAN PATROL GR V (5) Wagon (Y61) 2.7 TD | 05.1998 - 06.2001 | 105 | 95 | 90 |
Examples of Compatible Batteries
| Battery Specs | Battery Image |
|---|---|
Battery Brand: TUDOR Battery Code: TF1853 Voltage: 12 V Battery Capacity: 185 AH Height: 223 Width: 223 Length: 513 Cold Cranking Amps (CCA): 1150 A Post Positions: 3 Hold-down Type: B00 |  |
Battery Brand: VARTA Battery Code: 670103100A732 Voltage: 12 V Battery Capacity: 170 AH Cold Cranking Amps (CCA): 1000 A Post Positions: 3 Terminal Type: 1 Hold-down Type: B00 Length: 513 Width: 223 Height: 223 Battery Property: Heavy Duty (extended cycle and vibration proof) |  |
Battery Brand: BOSCH Battery Code: 0 092 T30 770 Voltage: 12 V Battery Capacity: 155 AH Cold Cranking Amps (CCA): 900 A Length: 513 Width: 223 Height: 223 Post Positions: 3 Hold-down Type: B00 Terminal Type: 1 |  |
Battery Brand: DETA Battery Code: DF1853 Voltage: 12 V Battery Capacity: 185 AH Height: 223 Width: 226 Length: 513 Cold Cranking Amps (CCA): 1150 A Post Positions: 3 Hold-down Type: B0 |  |
Battery Brand: VARTA Battery Code: 655013090A742 Voltage: 12 V Battery Capacity: 155 AH Cold Cranking Amps (CCA): 900 A Post Positions: 3 Terminal Type: 1 Hold-down Type: B00 Length: 513 Width: 223 Height: 223 Battery Property: Heavy Duty (extended cycle and vibration proof) |  |
Battery Brand: COMLINE Battery Code: CB335PL Hold-down Type: B1 Voltage: 12 V Cold Cranking Amps (CCA): 630 A Battery Capacity: 95 AH Post Positions: 0 Filled Weight: 20.3 kg Length: 304 Width: 173 Height: 220 |  |
Battery Brand: BOSCH Battery Code: 0 092 S40 280 Voltage: 12 V Battery Capacity: 95 AH Cold Cranking Amps (CCA): 830 A Length: 306 Width: 173 Height: 225 Post Positions: 0 Hold-down Type: B01 Terminal Type: 1 |  |
Battery Brand: PLATINUM Battery Code: 249E Voltage: 12 V Battery Capacity: 90 AH Cold Cranking Amps (CCA): 740 A Cold Cranking Amps (CCA) DIN: 59004 A Length: 304 Width: 174 Height: 225 Post Positions: 0 Terminal Type: T1 Hold-down Type: B01 |  |
Battery Brand: VMF Battery Code: 60032 Voltage: 12 V Battery Capacity: 100 AH Height: 220 Width: 173 Length: 303 Cold Cranking Amps (CCA): 740 A Post Positions: 0 Hold-down Type: B01 Terminal Type: 1 |  |
Battery Brand: VARTA Battery Code: 5954040833132 Voltage: 12 V Battery Capacity: 95 AH Cold Cranking Amps (CCA): 830 A Post Positions: 0 Terminal Type: 1 Hold-down Type: B01 Length: 306 Width: 173 Height: 225 |  |
Battery Brand: COMLINE Battery Code: CB335PR Hold-down Type: B1 Voltage: 12 V Cold Cranking Amps (CCA): 730 A Battery Capacity: 100 AH Post Positions: 0 Filled Weight: 21.6 kg Length: 304 Width: 173 Height: 220 |  |
Battery Brand: EXIDE Battery Code: EB954 Voltage: 12 V Battery Capacity: 95 AH Cold Cranking Amps (CCA): 720 A Length: 306 Width: 173 Height: 222 Post Positions: 0 Terminal Type: EN Hold-down Type: Korean B1 |  |
Battery Brand: EXIDE Battery Code: EC904 Voltage: 12 V Battery Capacity: 90 AH Cold Cranking Amps (CCA): 680 A Length: 306 Width: 173 Height: 222 Post Positions: 0 Terminal Type: 1 Hold-down Type: Korean B1 |  |
